laser safety goggle R14P1P16L
The laservision laser safety eyewear R14.P1P16.1003 with lip seal (L) is a goggle with a gold-colored filter and has a daylight transmission of approx. 40%. The goggle is particularly suitable for UV lasers and blue lasers up to 470 nm as well as IR lasers (diode, Nd: YAG, disk and fiber lasers) in the range 808 - 1100 and CO2 lasers. The changeable click frame with lip seal is preferably used by alternating users. The shipment includes a metal box which can also be used as a storage box.
- Order number: R14P1P161003
- GTIN: 4050369053564
- Pack unit: 1 pieces
- Weight incl. packaging: 0,61 kg
- Weight excl. packaging: 0,18 kg
Product number:
R14P1P161003
Product information "laser safety goggle R14P1P16L"
Protection range
ultraviolett
Protection within the ultraviolet spectral range between 180 and 400nm
visible
Protection within the visible spectral range between 400 and 700nm
near infrared
Protection within the near infrared spectral range between 700nm and 1400nm
Infrared
Protection in the infrared spectral range above 1400nm
| Coating: | no coating |
|---|---|
| Cushion: | Lip seal (L) |
| Filter: | P1P16 |
| Filter colour: | Gold |
| Filter curvature: | Flat filter |
| Filter material: | Plastic |
| Filter technology: | Absorption filter |
| Filter thickness: | ca. 6mm |
| Frame: | R14 |
| Frame type: | Goggle with strap |
| Properties: | Head support option, M-protection rating |
| Protection Class / Norm: | EN 207 full protection |
| Protection range: | Infrared, near infrared, ultraviolett, visible |
| VLT (approx.): | 40% |
| Visual brightness: | Very good |
| colour recognition: | Good |
| WAVELENGTH (NM) | OD | OPERATING MODE / TESTED PROTECTION LEVEL |
|---|---|---|
| 180 - 315 | (OD10+) | D LB10 + IR LB4 + M LB6Y |
| >315 - 464 | (OD8+) | D LB7 + IR LB8 + M LB8Y |
| >464 - 467 | (OD7+) | DIRM LB7 |
| >467 - 470 | (OD6+) | DIRM LB6 |
| >470 - 472 | (OD5+) | DIRM LB5 |
| >472 - 474 | (OD4+) | DIRM LB4 |
| >474 - 478 | (OD3+) | DIRM LB3 |
| >478 - 484 | (OD2+) | DIRM LB2 |
| >484 - 500 | (OD1+) | DIRM LB1 |
| 700 - <740 | (OD1+) | DIRM LB1 |
| 740 - <765 | (OD2+) | DIRM LB2 |
| 765 - <780 | (OD3+) | DIRM LB3 |
| 780 - <792 | (OD4+) | DIRM LB4 |
| 792 - <808 | (OD5+) | DIRM LB5 |
| 808 - <825 | (OD6+) | DIRM LB6 |
| 825 - <840 | (OD7+) | DIRM LB7 |
| 840 - <860 | (OD8+) | D LB7 + IR LB8 + M LB8Y |
| 860 - <880 | (OD9+) | D LB7 + IR LB8 + M LB8Y |
| 880 - 1070 | (OD10+) | D LB7 + IR LB8 + M LB8Y |
| >1070 - 1080 | (OD9+) | D LB7 + IR LB8 + M LB8Y |
| >1080 - 1086 | (OD8+) | D LB7 + IR LB8 + M LB8Y |
| >1086 - 1092 | (OD7+) | DIRM LB7 |
| >1092 - 1100 | (OD6+) | DIRM LB6 |
| >1100 - 1108 | (OD5+) | DIRM LB5 |
| >1108 - 1115 | (OD4+) | DIRM LB4 |
| >1115 - 1125 | (OD3+) | DIRM LB3 |
| >1125 - 1140 | (OD2+) | DIRM LB2 |
| >1140 - 1165 | (OD1+) | DIRM LB1 |
| 3945 - <5180 | (OD4+) | DI LB4 + R LB3Y |
| 5180 - 25000 | (OD7+) | D LB5 + I LB5Y + R LB3Y |
